jstree : jQuery 기반으로 트리형식의 구조를 지원해 웹에 출력을 도와주는 라이브러리
jstree, jquery 스크립트 및 css
<link rel="stylesheet" href="https://cdnjs.cloudflare.com/ajax/libs/jstree/3.2.1/themes/default/style.min.css" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/jstree/3.2.1/jstree.min.js"></script>
<script src="https://cdnjs.cloudflare.com/ajax/libs/jquery/1.12.1/jquery.min.js"></script>
1. node가 loaded 되었을때 실행 - $('#jstree').on('loaded.jstree', function (e, data) { });
2. node가 change 되었을때 실행 - $('#jstree').on('changed.jstree', function (e, data) { });
3. node가 select 되었을때 실행 - $('#jstree').on('select_node.jstree', function (e, data) { });
모든 node 열기 : $('#jstree').jstree('open_all');
select_node : 특정 노드 선택하기 - $('#jstree').jstree(true).select_node('특정 id');
create_node : 특정 노드 추가하기 - $('#jstree').jstree(true).create_node...
delete_node : 특정 노드 삭제하기 - $('#jstree').jstree(true).delete_node('특정 id');
<!DOCTYPE html>
<html lang="ko">
<head>
<%@ page language="java" contentType="text/html; charset=UTF-8" pageEncoding="UTF-8"%>
<!-- jsTree theme -->
<link rel="stylesheet" href="https://cdnjs.cloudflare.com/ajax/libs/jstree/3.2.1/themes/default/style.min.css" />
<style>
button {
/* 생략 */
margin: 0;
padding: 0.5rem 1rem;
font-family: "Noto Sans KR", sans-serif;
font-size: 1rem;
font-weight: 400;
text-align: center;
text-decoration: none;
display: inline-block;
width: auto;
border: none;
border-radius: 4px;
}
#event_result{
font-size: 1rem;
font-weight: 400;
padding: 0.5rem 1rem;
}
</style>
</head>
<body>
<div id="jstree"></div>
<div id="event_result"></div>
<button id="clickBtn">click event</button>
<button id="btnCreate">create node</button>
<button id='btnDelete'>delete node</button>
<!-- jQuery -->
<script src="https://cdnjs.cloudflare.com/ajax/libs/jquery/1.12.1/jquery.min.js"></script>
<!-- jsTree -->
<script src="https://cdnjs.cloudflare.com/ajax/libs/jstree/3.2.1/jstree.min.js"></script>
<script>
$(function() {
// 테스트 겸 json data 생성. 추후 ajax로 변경 할 예정
// parent : 상위 node의 아이디를 지정하여 부모 관계를정함. parent가 '#'인 경우는 최상위 레벨의 노드를 나타냄.
// id : node의 id를 지정
// text : node의 이름을 지정
var data = [
{ "id" : "p1", "parent" : "#", "text" : "Parent-1" },
{ "id" : "p2", "parent" : "#", "text" : "Parent-2" },
{ "id" : "p3", "parent" : "#", "text" : "Parent-3" },
{ "id" : "c1", "parent" : "p1", "text" : "Child-1" },
{ "id" : "c2", "parent" : "p1", "text" : "Child-2" },
{ "id" : "c3", "parent" : "p1", "text" : "Child-3" },
{ "id" : "c4", "parent" : "p2", "text" : "Child-4" },
{ "id" : "c5", "parent" : "p2", "text" : "Child-5" },
{ "id" : "c6", "parent" : "p3", "text" : "Child-6" },
{ "id" : "g1", "parent" : "c6", "text" : "Grand-1" },
{ "id" : "g2", "parent" : "c6", "text" : "Grand-2" },
];
// [ajax 구현일경우]
// $('#jstree').jstree({
// 'core': {
// 'data': {
// 'url': '/url',
// 'dataType': 'json'
// }
// }
// });
// 인스턴스를 생성
// jstree의 node 데이터 가져오기
$('#jstree').jstree({
"core": {
"check_callback": true,
"data": data
},
}).on('create_node.jstree', function(e, data) {
console.log('saved');
});
// 이벤트를 설정
// btnCreate 버튼 클릭 시
$('#btnCreate').click(function() {
console.log("btnCreate");
// 부모 임의 생성 테스트 parent는 #임
$('#jstree').jstree(true).create_node('#', {"id": "p4", "text": "Parent-4"}, "last", function() {
console.log('Parent Created');
});
//자식 임의 생성 테스트 create_node('생성할 노드의 부모 노드', {생성할 노드의 정보}, 순서)
$('#jstree').jstree(true).create_node('p3', {"id": "c7", "text": "Child 7"}, "last", function() {
console.log('Child Created');
});
});
$('#btnDelete').click(function() {
console.log('btnDelete');
// 위에서 임시 생성한 부모 p4 삭제
$('#jstree').jstree(true).delete_node('p4');
});
// node loaded 되었을때 함수
$('#jstree').on('loaded.jstree', function (e, data) {
console.log('loaded.jstree');
// loaded 되었을때 모든 node 열기
//$('#jstree').jstree("open_all");
// loaded 되었을때 특정한 node 열기
$('#jstree').jstree('open_node', 'p1');
});
// node가 change 되었을때 함수
$('#jstree').on('changed.jstree', function (e, data) {
console.log(data.selected);
var i,j,r = [];
for(i = 0, j = data.selected.length; i < j; i++) {
r.push(data.instance.get_node(data.selected[i]).text);
}
// div에 현재 선택 된 값을 나타내기 위함.
$('#event_result').html("* [ selected ] : " + r.join(', '));
});
// node select 되었을때 함수
$('#jstree').on('select_node.jstree', function (e, data) {
console.log("select.jstree");
});
// clickBtn 버튼 클릭 시
$('#clickBtn').on('click',function(){
console.log('clickBtn click');
// clickBtn 버튼 클릭 시 특정 node 선택되게
$('#jstree').jstree(true).select_node('c5'); // 버튼 클릭 시 특정 노드 선택되게 (id로)
});
});
</script>
</body>
</html>
참고 : https://github.com/vakata/jstree/blob/master/demo/basic/index.html
